Missing coolant tank with the pump. We can fabricate one for you, or you can easily make one yourself. This machine is like new, from 2017. We have all the documentation and backup available. It's currently connected and ready for use.
Product Info
Missing coolant tank with the pump. We can fabricate one for you, or you can easily make one yourself. This machine is like new, from 2017. We have all the documentation and backup available. It’s currently connected and ready for use.
Specifications
Working table:
Dimensions (mmmm): 500 mm x 300 mm
Working area (mmmm): 430 mm x 290 mm
Bolt hole: 12mmx3
Maximum loading capacity: 100 Kg
Stroke limit:
X axis (mm): 420 mm
Y axis (mm): 320 mm
Z axis (mm): 228 mm
Distance from spindle nose to working table surface (mm): 100-328 mm
Distance from spindle center to slide surface: 390 mm
Spindle:
Taper: ISO No.30
Diameter (mm): 50 mm
Speed (rpm): 80~8000 RPM
Feed rate:
Cutting feed rate: 1~4000 mm/min
Rapid traverse rate: 30 m/min
Tool magazine:
Capacity (no. of tool): 12 pieces
Method of tool selection: Bi-Direction and Shortest path
tool size (tool diameter length)(with adjacent tools): 75 mm x 200mm
